> Paper tube core machine

This machine can make the paper core from fluting paper roll .the paper roll have been cut into with small width .this machine can coat glue on paper and rotate it into paper core.


1.Using computer PLC and frequency control system,low noise; 2.Saving power, it can save 50% electricity than ordinary electromagnetic speed adjustment; 3.Locating by infrared ray, automatic cutting; 4.Double blade,single blade or saw blade are in common use,adjust the cutting length of the paper core arbitrarily; 5.Automatic Gluing, easy operate; 6. The digital control panel set various operating function,can set arbitrary workings on the machine;

Technical Parameter
1 ply of paper 3-21ply
2 inner diameter of paper core 20-400mm
3 wall thickness of paper core 10-20mm
4 working speed 3-25m/min(max can be 30m/min)
5 paper length control system photoelectric
6 head quantity for paper winding 4 head
7 cutting style single round blade
8 glue feeding system double surface glue
9 power 11kw
10 input power 3phrase, 380V, 50-60HZ
11 Operation workers 1-2 workers
