> Toilet paper machine
Function:

The full automatic 2880mm model toilet paper roll processing line includes toilet paper rewinding machine, automatic bandsaw cutter and automatic toilet paper packing machine. This toilet tissue paper production line is used to make well packed small toilet tissue roll from jumbo parent paper roll.

Contact Us:

Whatsapp/Mobile: 0086-13937183852

Email: andy@xingtumachine.com


Features

1.automatically change jumbo roll;

2.trimming paper precisely;

3.automatically spray glue;

4.automatically perforating;

5.automatically embossing;

6.easy to operate and maintain;

7.low noisy;

Technical Parameter
Machine Model 1092 1575 2000 2200 2400 2600 2800
Width of jumbo roll (mm) 1200 1800 2000 2200 2400 2600 3000
Finished Toilet Roll Diameter 80~120mm (Tightness can be adjustable)
Finished Toilet Roll Inner Diameter 32~60 mm
Jumbo roll diameter (mm) 1200 (Other sizes please point out)
Jumbo Roll Inner Diameter 76.2 mm(other sizes please point out)
Perforation distance (mm) 4 blade,90~160mm; 2 blade,180~320mm;
Production speed 160-200 m/minute
Parameter set Touching-screen HMI Operation System
Controller PLC program
Mechanical driving AC frequency converter, stepless speed regulation
Air pneumatic system 3 Pa (air-compressor), the minimum pressure 5kg/cm2 pa (prepared by buyer)
Power 4kw-10kw (380V 50Hz)
Chosen items (Should be ordered separately)
Embossment Single embossment, Double embossment, Edge embossment
Embossment down roller Rubber roller, steel roller
Jumbo roll stander 1-3 plies
Rewinding unit Core or coreless
Other special request for machine is welcome
